Energy-saving Unbidirectional Ceramic Filter
Product Details
Scope of application
Application and positioning of a ceramic filter in a general mineral processing flow-sheet
Ceramic filers are generally applied in dewatering of non-sticky and non-oily materials, with good water permeability, low deposition speed, and particle size ranging from 80 to 350 mesh, in fields such as iron ore, cooper, gold, lead, zinc, quartz, potash, feldspar, sewage sludge, desulfurization in power plants, chemical material slurry and others.
Cake moisture and ceramic filter capacity for some standard filtered products
Filtered Products | Cake moisture | Capacity |
Iron ore concentrate | 7%-9% | 900kg/㎡.h |
Iron ore tailings | 10%-12% | 450kg/㎡.h |
Copper concentrate | 10%-12% | 400kg/㎡.h |
Copper tailings | 12%-14% | 180kg/㎡.h |
Gold concentrate | 11%-13% | 350kg/㎡.h |
Gold tailings | 13%-15% | 180kg/㎡.h |
Lead/zinc concentrate | 9%-11% | 400kg/㎡.h |
Lead/zinc tailings | 12%-14% | 280kg/㎡.h |
Sulfur concentrate | 9%-11% | 350kg/㎡.h |
Quartz concentrate | 8%-10% | 400kg/㎡.h |
Quartz concentrate | 12%-14% | 200kg/㎡.h |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
5 | 12 | 192 | |
LH-80 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
14000 | 57 | 7290/3595/3205 | |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
5 | 12 | 240 | |
LH-100 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
15000 | 65 | 8490/3595/3205 | |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
6 | 12 | 240 | |
LH-120 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
18000 | 75 | 7802/3550/3198 | |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
12 | 15 | 180 | |
LH-144 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
53000 | 130 | 9050/5342/4786 | |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
12 | 15 | 210 | |
LH-168 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
55000 | 134 | 9850/5342/4786 | |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
12 | 15 | 255 | |
LH-204 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
58000 | 137 | 11050/5342/4786 | |
Model | filter area/circle㎡ | Number of turns | umber of filter units/machine |
12 | 15 | 300 | |
LH-240 | total disks | total weight of the machine（kg） | total power of the machine（kw） |
61000 | 140 | 12250/5342/4786 |
